Curated diagram types for Claude Code, directly useful for AI-assisted development workflows.
Summary
Cathryn Lavery's Diagram Design tool, now at v2.3, provides 27 editorial-quality diagram types as a single agent skill for Claude Code, Codex, and Pi. It uses semantic system patterns that decouple behavior from layout, allowing queues, policy traces, or trust boundaries to reuse existing types without expanding the type count. Static HTML output remains the default, with optional accessible motion for ordered explanations, and the skill can redraw draw.io or Mermaid sources at a chosen format, size, and detail level.
Author
cathrynlavery
